Your coding agent should draw diagrams

Coding agents talk in text. That is fine for a diff, but it is a terrible medium for architecture.

Coding agents talk in text. That’s fine for a diff, but it’s a terrible medium for architecture. When I ask an agent “how does auth flow through this service?”, the honest answer is a diagram — boxes, arrows, a fork where a request can go two ways. A wall of prose is the wrong shape for that.

So I taught pi-go to draw Mermaid diagrams in the terminal, and the interesting part turned out to be everything that isn’t the diagram.

Why not just render to an image?

The obvious move is to shell out to a headless browser, render the Mermaid to PNG, and show it. That’s what most tools do. It’s also wrong for a TUI:

• It needs a browser and a network round-trip on every diagram.
• The result is a bitmap, which doesn’t fit a text terminal’s layout, doesn’t reflow, and can’t be selected or copied.
• It’s slow. A diagram should appear as fast as the agent’s next sentence.

The right output for a terminal is text — Unicode box-drawing characters, laid out to the width of the pane. So I built a renderer that turns Mermaid syntax into terminal art, adapted from the MIT-licensed mmaid-go engine and then pushed well past where it started.

The hard part is measuring text, not drawing boxes

Drawing a box is easy. Knowing how wide the box must be is not.

The original engine sized every box, centered every label, and placed every edge caption with len(s) — the byte count. That is the display width only for ASCII. The moment a label carries an emoji, it measures four columns per glyph and draws two, so the box comes out too wide and the text sits off-center. CJK has the opposite problem: it measures one column per glyph and draws two, so the text overruns its border.

The fix is a small package that measures text in terminal columns, implementing a deliberate subset of Unicode’s UAX #11:

• combining marks and zero-width joiners take no space;
• East Asian Wide/Fullwidth characters and emoji take two columns;
• everything else takes one.

The subtle case is a variation selector. U+FE0F asks for emoji presentation, which turns an otherwise narrow symbol into a two-column glyph. It carries no width of its own, so measuring rune-by-rune misses it: 🛠️ is two columns and 🛠 is one, and the only difference is a zero-width code point. The width function has to resolve that before it can answer.

This is a subset of the full width table on purpose — enough to place a label correctly, and small enough that the package depends on nothing outside the standard library.

The security work nobody sees

A diagram is untrusted input. The agent generates it, but the agent is fed by the world, and a label can smuggle a terminal escape sequence. So the renderer:

• strips terminal escapes from labels before they ever reach the canvas;
• bounds the packet size so a pathological diagram can’t balloon memory;
• recovers from panics in the parser and renderer, returning an error string instead of unwinding into the caller’s view.

Nothing in the package writes to stdout or stderr, so it’s safe to call from inside the TUI’s render path.

The bug that rotted overnight

The golden tests caught something wonderful. One corpus case references after b a, which the parser doesn’t resolve, so that task falls back to time.Now() — and the chart’s axis label is literally today’s date. The approved golden therefore encoded the day it was generated and failed on the next date change, blocking every open PR until someone re-approved it. Re-approving only bought another day.

The fix routes the gantt clock through a package variable and freezes it in the test’s TestMain, so a golden is a function of its input alone. Production code never assigns it. And the regenerated golden is a better approval than the one it replaces: reading the real clock had stretched the axis from 2017 to 2026, which squashed every task into a single cell. Against a frozen date, the same input renders actual bars and puts the today-marker inside the range.

Teaching the model when to draw

A renderer is only half the story. The other half is teaching the agent when to emit Mermaid instead of an ASCII tree. The system prompt now distinguishes the two:

• Mermaid for flowcharts and processes — anything with arrows and decisions;
• ASCII + emoji for structure — package maps, folder trees, “what belongs to what”.

The TUI paints diagram regions with a background rather than just an outline, gives boxes, connectors, and groups distinct styles, and pads boxes tightly so they aren’t mostly empty. A diagram in a terminal should look like a diagram, not a wall of +----+ characters.

What it adds up to

The renderer is ~1,500 lines across a parser, a graph model, a canvas, and a text-width package. The interesting engineering was never the drawing — it was measuring columns correctly, sanitizing untrusted labels, and making the tests deterministic. That’s the difference between a feature that works in a demo and one that survives a year of real use.

If you’re building a terminal tool that wants to show structure, steal the text-width idea first. It’s the piece everything else hangs off, and it’s the one everyone gets wrong.
